Xterra SB4.5r User Manual

4
SB4.5r Fitness Bike
SB4.5r Assembly Pack Checklist
Hardware Step 1
#81. M5 x 12mm
Phillips Head Screw
(4 pcs)
#73. 5/16”
Split Washer
(6 pcs)
#70. 5/16” x 18mm
Flat Washer
(6 pcs)
#90. 5/16” x 1-1/4”
Hex Head Bolt
(4 pcs)
#96. 3/8” x 3-1/2”
Carriage Bolt
(2 pcs)
#95. 5/16” x 3/4”
Button Head Socket Bolt
(6 pcs)
#99. M6 x 15mm
Phillips Head Screw
(4 pcs)
#97. 3/8” x 23mm
Curved Washer
(2 pcs)
#98. 3/8”
Cap Nut
(2 pcs)

Xterra SB4.5r Specifications

General

Brand	Xterra
Model	SB4.5r
Category	Exercise Bike
Language	English
