Xterra UP150 - Pedal and Bottle Holder Attachment

customerservice@dyaco.ca
DyacoCanadaInc2017

12


UB150

ASSEMBLYINSTRUCTIONS

5PEDALANDBOTTLEHOLDER

9
1
10
45
76
38

1. Theleftandrightpedals(9&10)aremarked“L”&
“R”.Attachthestrapstothepedals.Connectthe
rightpedal(10)tothecrank(38)ontherighthand
sideofthecycleasyousitonit.Repeatfortheleft
pedal(9).
Note:Therightpedalshouldbethreadedonclockwiseand
theleftpedaloncounter‐clockwise.
2. Attachthebottleholder(76)tothefrontpostand
tightenwithtwoself‐tappingscrews(45)which
arepre‐assembledonthefrontpost.









