4SEATASSEMBLY

1
17
11
47
48
49
7
8
19


1. Attachtheseat(8)toseatpost(7)andtightenwith
carriagebolt(47),squareplate(48),spacer(49)and
clubknob(19)whicharepre‐assembledontheseat
post(7). 
2. Insertseatpost(7)throughcoverforseatpost(17)and
thenintomainframe(1).Lineuptheholesandsecure
seatinpositionwithquickreleaseknob(11).The
correctheightforseatcanbeadjustedafterthebikeis
fullyassembled.











Hardware Step 4
1 Quick Release Knob (#11)
