① A80 BT Mainframe
② VCI box (can be directly connected to the vehicle diagnostic
seat or select ③⑤ Accessory after connecting the vehicle diagnostic
seat)
③ Adapter cable (optional for non-standard OBD II 16pin
connectors)
④ Measured vehicle
⑤ Adapter (optional for non-standard OBD II 16pin connectors)
3.2 Precautions Before Use
（1）Battery voltage range on the car: +9~+36VDC.
（2）When the test harness is unplugged, the application hand pinch the
head of the front end of the wire harness to unplug, do not pull the middle
segment of the wiring bundle, and the plug connection beam sees the
direction of the corresponding interface flat plug, and does not tend to be
inserted to avoid damaging the terminal.
（3）When carrying out some special functions tests, users are required to
operate the device according to operating instructions. For some tests the
vehicle has to meet certain requirements, for example: engine temperature
80℃/105℃, turn off loads (such as headlights, air-conditioner, etc.), put
accelerator pedal in released position, etc.
