Fig 4-1 How to connect to the vehicle
1
Tablet
2
Main Test Cable with OBDII-16 Connector
3
Vehicle
※
Note: Please make sure all the cables are connected tightly; The vehicle’s DLC is not
always located under the dash; for the location of the DLC, please refer to the vehicle’s
user manual.
Precautions for Diagnosis
1. The battery voltage range on the car: +9~+36V DC;
2. When testing some special functions, the operator must operate
according to the prompts and meet the test conditions. For some
models [special functions], the conditions that need to be met are:
engine water temperature 80 ℃ ~105 ℃ , turn off headlights and air
conditioners, Keep the accelerator pedal in the released position, etc.;
3. As the electronic control systems of different models are more
complicated, if you encounter situations where it is impossible to test or
a large amount of test data is abnormal, you can search for the ECU of
the vehicle and select the menu through the model on the ECU
nameplate;
4. If the vehicle type or electronic control system to be tested is not
found in the H6 Elite diagnostic function, please upgrade the vehicle
diagnostic software to the latest version or consult the technical service
department;
5. It is forbidden to use wiring harnesses other than Xtool for
connection testing to avoid unnecessary losses;
6. In the communication between the H6 ELITE Smart Diagnostics
System and the vehicle, it is forbidden to shut down directly. You
should cancel the task before returning to the main interface.
