VESDA-EVEP-A00-P Product Guide
www.xtralis.com 9
2.7 Specifications
Specification Value
Supply Voltage 18 to 30 VDC (24 VDC Nominal)
Power Consumption @24 VDC
Aspirator Setting 1 Setting 5 Fixed
VEP-P Power (Quiescent) 7.0 W 8.8 W -
Power (In Alarm) 7.8 W 9.6 W -
VEP-1P Power (Quiescent) - - 8.8 W
Power (In Alarm) - - 9.6 W
Dimensions (WHD) 350 mm x 225 mm x 135 mm
(13.8 in x 8.9 in x 5.3 in)
Weight 4.4 kg (9.7 lbs)
Operating Conditions
Please consult your Xtralis representative for
information on operation outside these parameters
or where sampled air is continually above 0.05%
obs/m (0.015% obs/ft) under normal operating
conditions.
Temperature:
l Ambient: 0°C to 39°C (32°F to 102°F)
l Sampled Air: -20°C to 60°C (-4°F to 140°F)
l Tested to: -20°C to 55°C (-4°F to 131°F)*
* UL:-20°C to 50°C (-4°F to 122°F)
Humidity:
l 5-95% RH, non-condensing
Storage Conditions
(Non-operational)
l Humidity: Dry (<95%)
l Temperature: 0° to 85°C
l Must not be exposed to sunlight or other radiation sources
Sampling Pipe Network l Maximum length per pipe when using four straight
pipes:
l Four pipe VEP-A00-P:70 m (230 ft)
l One pipe VEP-A00-1P: 100 m (328 ft)
l Maximum total pipe length (with branches):
l Four pipe VEP-A00-P:560 m (1,837 ft)
l One pipe VEP-A00-1P: 130 m (427 ft)
l Pipe Modeling Design Tool:ASPIRE
l Refer to Section 3.1 Design Considerations.
Note: Standards compliance of a particular pipe network
must be determined using ASPIRE.
Inlet Pipe Size l External Diameter: 25 mm or 1.05 in (3/4" IPS)
Exhaust Pipe Size l External Diameter: 25 mm or 1.05 in (3/4" IPS) via
adaptor
Relays l 7 programmable relays
l Contacts rated 2A @ 30 VDC (Resistive)
l Programmable to latch or not latch alarm or fault states
IP Rating IP 40
(not UL tested)
Mounting Upright or inverted
Cable Access 4 x 26 mm (1 in) ports
Cable Termination Screw terminal blocks (0.2-2.5 sq mm, 24-14 AWG)
Interfaces l USB (Type 2)
l Ethernet (RJ45)
Table2-2: VEP-A00 Detector Specifications
