VESDA-EVEP-A00-P Product Guide
www.xtralis.com 67
Parameter Default Values Range Affected by Return to
Factory Defaults
command
Minimum Maximum
l Enabled Unchecked Unchecked Checked Yes
l Start Holiday
Date
Blank n/a n/a Yes
l End Holiday Date Blank n/a n/a Yes
Air Flow
Air flow thresholds
l Major High 130% 105% 200% Yes
l Minor High 120% 105% 200% Yes
l Minor Low 80% 25% 95% Yes
l Major Low 70% 25% 95% Yes
Delay 30 seconds 15 seconds 250 seconds Yes
Significant Flow
Change
2.0 L/min 0.5 L/min 5 L/min Yes
Pipes in Use All pipes in use No pipes in use All pipes in use Yes
5
Aspirator Speed Setting 1 Setting 1 Setting 5 Yes
6
Filter
Service Interval 731 days 1 day 3655 days Yes
Referencing
Referencing Enabled Unchecked Unchecked Checked Yes
Detector Blank Zone 1 Zone 254 Yes
Delay 2 minutes 0 minutes 15 minutes Yes
Dilution Factor 100% 1% 100% Yes
General Purpose Inputs
GPI Function
(Unmonitored)
Reset n/a n/a Yes
GPI Function
(Monitored)
Mains OK n/a n/a Yes
Button Lockout Unchecked Unchecked Checked Yes
Relays
Assignment of Relays
to conditions
See Table4-2 n/a n/a Yes
Normally Energized See Table4-2 n/a n/a Yes
Latching Checked Unchecked Checked Yes
Beep Unchecked Unchecked Checked Yes
AutoLearn Smoke and Flow Commands
Duration 14 days 15 minutes 16 days n/a
Table5-4: Default Settings (continued...)
1
The Xtralis VSC software forces the user to move the detector to a valid zone number.
2
The user must set the password the first time. There is no default password.
3
Default value set in factory. Not modified by return to factory defaults command.
