Table 5-8: Maintenance Parameters
Parameter
Description
LASERIN Current smoke value for the laser detector output
LASERHI Additional smoke detector data (Factory Use)
LASERM Additional smoke detector data (Factory Use)
LASERLO Additional smoke detector data (Factory Use)
REL IN Current Pressure Sensor reading
ABS IN REL IN value at last flow normalization
PRSCOMP Pressure sensor temperature compensation value
(Factory Use)
S1 COIL Suppression Control Module S1 COIL value
S1 TEST Suppression Control Module S1 TEST value
A1 COIL Suppression Control Module A1 COIL value
A1 TEST Suppression Control Module A1 TEST value
P1 NORM Suppression Control Module P1 NORM value
P1 TEST Suppression Control Module P1 TEST value
C1 NORM Suppression Control Module C1 NORM value
C1 TEST Suppression Control Module C1 TEST value
S2 COIL Suppression Control Module S2 COIL value
S2 TEST Suppression Control Module S2 TEST value
A2 COIL Suppression Control Module A2 COIL value
A2 TEST Suppression Control Module A2 TEST value
P2 NORM Suppression Control Module P2 NORM value
P2 TEST Suppression Control Module P2 TEST value
C2 NORM Suppression Control Module C2 NORM value
C2 TEST Suppression Control Module C2 TEST value
MOD1 IN Identification number of Module 1
MOD2 IN Identification number of Module 2
MOD3 IN Identification number of Module 3
MOD4 IN Identification number of Module 4
MOD5 IN Identification number of Module 5
5.3.12 TEST OUTPUTS: Testing Mode
Minimum Access Code Required: Level 2
This menu item enables the user to manually increase or decrease smoke and flow levels for the detector in
order to simulate real fire and flow events. This enables the user to test the responses of the detector to fire
and flow events without the need to conduct smoke tests or blocking/unblocking the sampling network. Note
that all alarms and relays will operate as if the system is reacting to a real event.
