VESDA VFT Product Guide
VESDA by Xtralis
62 www.xtralis.com
CN7: Output Relay Interface
1 FIRE 2 C Requires 7 x 0.2 - 6 A (24 AWG) cable
Note: Maximum relay contact rating is 2 A @ 30 VDC.
Refer to Section 5.4.1 for further details.
2 NC
3 NO
4 FIRE 1 C
5 NC
6 NO
7 ACTION C
8 NC
9 NO
10 ALERT C
11 NC
12 NO
13 FAULT C
14 NC
15 NO
