ASPIRE Software
7-22 VESDA Student Workbook
171
Two grille coverage using one detector
• VEP-1P or VLF-500 are good
detectors for this project
• The overall number of SP
(Sample Ports) should be
limited to prevent excessive
dilution
Two grille coverage using one detector
• Expand detector
• Select Ceiling Right, right-
click and Delete (or left-click
and select X)
• Select Ceiling Left, right-
click and Delete (or left-click
and select X)
