-35-
4
4
Long
Screw
Waterproof
Case
1
1
2
2
3
3
+
++
Short
Thumbscrew
Step 1:
Interlock the mounting fingers between Water-
proof Case, J-Base, Extension Mount, Long Thumbscrew,
Short Thumbscrew, and then secure them with screws.
Step 2:
Slide the Helmet Base into the Waterproof Case
Mount bottom until it clicks into place.
Step 3:
Stick the Adhesive Pads on the bottom of the
Helmet Base. Find a suitable position and fix the camera on
the helmet.
Method D:
Bicycle
Mount
