-36-
2
Step 1: Interlock the mounting fingers between Water-
proof Case, Bicycle Mount, Short Thumbscrew, and then
secure them with screws.
Step 2: Find a suitable position and fix the camera on the
bicycle.
TIPS：
If you don’t like to mount the camera with the Waterproof
Case, you can use the Adapter 2 to mount the camera
directly.
2
1 1
3
4
5
3
Action
Camera
Action
Camera
Adapter 2
Adapter 2
Long
Screw
Long
Screw
Bicycle
Mount
Waterproof
Case Mount
