Shows the transferred frames and
network bandwidth.
AUDIO Adjust the volume. The audio can be
turned on or off by clicking the audio
icon.
LOG WINDOW
Operations of the display mode of the main screen
Single channel display - Click the one of channel button or double-click the channel screen.
QUAD/-screen display - Click the QUAD button to switch to quad-screen display
Full screen display - Click the maximize button to display only screen and hidden the operation panel.
Image capture of live screen
Still-image of live screen can be captured and saved as BMP or JPEG file.
1. Click the channel to be captured. Then the channel screen is surrounded with a red line.
2. Click the CAPTURE button. Then the IMAGE CAPTURE dialog is displayed.
To Next Page
