HDD INSTALLATION GUIDE
1. Remove the unit’s cover. 2. Fix the supplied rubber pads to the
supplied HDD mounting bracket. Then fix
the hard disk to the mounting bracket
using the supplied screws (A).
3. Connect the unit’s power cable (B) and the supplied S-ATA cable (C) to the hard disk. Then
fix the hard disk to the unit using the supplied HDD fixing screws (D).
