CONTENTS
Safety __________________________________ 2
Data plate interpretation ________________ 4
Product description ____________________ 5
General design of a Flygt pump _________ 6
Installation ______________________________ 7
Electrical connections __________________ 8
Cable chart ____________________________ 10
Transportation and storage ____________ 14
Operation ______________________________ 14
Care and maintenance _________________ 15
Oil change _____________________________ 17
SAFETY
General Danger:
Safety instructions in this manual,
which could cause danger to life if
not observed, have been specifi-
cally highlighted with this general
danger symbol.
High Voltage:
The presence of a dangerous volt-
age is identified with this safety
symbol.
Non-observance to this warning
could damage the unit or affect its
function
This manual contains basic information on the installa-
tion, operating and maintenance and should be followed
carefully. It is essential that these instructions are
carefully read before installation or commissioning by
both the installation crew as well as those responsible
for operation or maintenance. The operating instruc-
tions should always be readily available at the location
of the unit.
WARNING!
Qualifications of personnel
An authorized (certified) electrician and mechanic shall
carry out all work.
Safety regulations for the owner/operator
All government regulations, local health and safety
codes shall be complied with.
All dangers due to electricity must be avoided (for
details consult the regulations of your local electricity
supply company).
Unilateral modification and spare parts manu-
facturing
Modifications or changes to the unit/installation should
only be carried out after consulting with Flygt.
Original spare parts and accessories authorized by the
manufacturer are essential for compliance. The use of
other parts can invalidate any claims for warranty or
compensation.
Dismantling and re-assembly
If the pump has been used to pump hazardous media,
care must be taken that, when draining the leakage,
personnel and environment are not endangered.
All waste and emissions such as used coolant must be
appropriately disposed of. Coolant spills must be
cleaned up and emissions to the environment must be
reported.
The pumping station must be kept tidy and in good
order at all times.
All government regulations shall be observed.
Identification of safety and warning symbols
The pictures in this manual may differ somewhat from the delivered pump depending on the hydraulic end configuration.
