Xylem Goulds 3HM Technical Manual

PAGE 13
Commercial Water
Goulds Water Technology
e-HM™ SERIES
MECHANICAL SEALS
LIST OF MATERIALS
Components
Part Number
1 2 3 4 and 5
Rotory Face Stationary Face Elastomers Hardware
Materials
B - Carbon E - EPDM (EPR) All 316 SS
Q - Sil Carbide : - :iton
: - Ceramic
PRESSURE AND TEMPERATURES LIMITS
Seal Code
1HM, 3HM 5HM 10HM, 15HM, 22HM
2-6 Stages 7+ Stages 2-5 Stages 6+ Stages All Stages
BQE 147PSI at 248F 235PSI at 248F 147PSI at 248F 235PSI at 248F 235PSI at 248F
BQ: 147PSI at 248F 235PSI at 248F 147PSI at 248F 235PSI at 248F 235PSI at 248F
QQE 147PSI at 248F 235PSI at 194F 147PSI at 248F 235PSI at 194F 235PSI at 194F
QQ: 147PSI at 248F 235PSI at 194F 147PSI at 248F 235PSI at 194F 235PSI at 194F
B:E 147PSI at 194F Not Available 147PSI at 194F Not Available Not Available
