23
8.3 Assembly instructions
HV 2.015 – HV 4.110 HV 4.150 – HV 4.220
display
actual value sensor
motor conduit box
4 mountin
g
clam
p
s
centerin
g
bit
4 screws
M5x70
motor cable
HYDROVAR – top cover
4 screws (to fit cover)
M4x50 M5x20
PTC
motor fan cover
motor
4 screws
M6x70
