10
1. Prepare a universal projector ceiling mount.
(Not included in the package)
2. Use
M5*15mm
screws to securely install the projector on the ceiling using the hanger
frame.
Install on the Ceiling
Screw Holes M5*15mm
155mm
108mm
Distance and Projection Size
The
recommended projection distance
is about
8.9 ft
, and the
shortest projection
distance
is 4.5 ft.
The image size depends on the
distance between projector and screen
.
There may be
3%
deviation among above listed data.Different settings cause various
distances.
40"
1.4m
(4.5ft)
2.1m
(6.7ft)
2.7m
(8.9ft)
3.4m
(11.2ft)
4.1m
(13.4ft)
6.8m
(22.4ft)
60"
80"
100"
120"
150"
200"
