Yadea M6L - Left and Right Flat Fork Guard Plate

Seat cushion disassembly check
●Screw ②
Check
Assemble in reverse order of disassembly.
Left and right flat fork guard plate
17
Job order Quantity Remark
4
1
1
2
1
1
1
Job name/part name
Seat barrel mounting bolt
Lithium battery compartment open cable
Seat barrel
Lithium battery lock
Cable fixing plate
Circlip
Seat cushion
Installation takes place in reverse order of removal
Check: open seat cushion, key open
battery compartment cover plate,
as shown
Remove the three components to
remove the seat barrel seat cushion
combination
1
2
3
4
5
6
7
●Seat cushion mounting plate ①
●Seat cushion skin wear/scratch/damage
→ replacement
Vehicle body parts
