Throttle fault repair determination method
1.Input signal check
No signal
input
There is a signal input
2.Output voltage check
No voltag
e input
There is a voltage input
Judge turn OK
3.The terminals check
No
Determine the terminal OK
Yes
Yes
Replace the terminals
4.Wire check
Wire appearance: no break open road,
insulation skin no breakage.
No
Determine the wire OK
Replace the transfer
5.Hall check
Use a master meter or a dedicated inspection
instrument to perform Hall's performance
checks.
Performa-
nce OK
Judge hall OK
Performance NG
Replace the transfer
45
Function definition: the speed adjustment is achieved by turning the output of 0.8V - 4.2V or so continuous
linearly changing voltage signal.
Common fault: throttle failure (turn throttle no response)
Diagnostic and troubleshooting procedures for the fault：
Performance check: Using the multimeter DC
voltage test transfer input signal voltage,
should comply with: 5± 0.5V.
1.Check the wiring terminals.
2.Wire check.
3.Check the hall device.
Judge turn OK
Performance check: Using the meter DC
voltage test transfer output voltage, should
comply with: low-end 0.8± 0.1V, high-end
3.6± 0.1V.
4.Check the wiring terminals.
5.Wire check.
6.Check the hall device.
Plug-in appearance: no breakage, no
oxidation of internal terminals, no rust, no
breakage.
Electrical system
