Yaesu FT-2DR - Parts List; AT2 xxx; BT2 xxx; C 2 xxx

CNTL-7
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG YAESU P/N VERS. LOT SIDE LAY ADR
CNTL Unit
Parts List
FT2DR/DE Technical Supplement
PCB with Components CS2357702
ø
USA: A2U
CS2357703
ø
EXP: B3
CS2357704
ø
EU: B2
CS2357705
ø
AUS: H2
CS2357707
ø
EU: C2
AT2001 CHIP ANTENNA ACD-5036-A3-CC-S Q3000263 1- B b1
BT2001 LITHIUM BATT. ML614R-TT31 Q9000895 1- B c1
C 2001 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 1- B b4
C 2002 CHIP CAP. 22pF 50V CH GRM1552C1H220JA01D K22178220 1- B b4
C 2003 CHIP CAP. 10uF 4V X5R GRM155R60G106ME44D K22179733 1- B b4
C 2006 CHIP CAP. 220pF 50V B GRM155B11H221KA01D K22178801 1- B c4
C 2009 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B c5
C 2010 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 1- B c2
C 2016 CHIP CAP. 0.012uF 25V B GRM155B11E123KA61D K22148836 1- B b4
C 2019 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B a2
C 2020 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c2
C 2021 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 1- B c2
C 2022 CHIP CAP. 0.012uF 25V B GRM155B11E123KA61D K22148836 1- B b5
C 2023 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B a2
C 2030 CHIP CAP. 10uF 4V X5R GRM155R60G106ME44D K22179733 1- B b1
C 2031 CHIP CAP. 10uF 4V X5R GRM155R60G106ME44D K22179733 1- B b1
C 2032 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B a2
C 2033 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B a2
C 2034 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B a2
C 2036 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B b1
C 2041 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 1 B c2
C 2041 CHIP CAP. 1uF 10V B GRM155B31A105KE15D K22108809 2- B c2
C 2042 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c2
C 2052 CHIP TA.CAP. 1uF 16V TMCP1C105MTRF K78120076 1- B a2
C 2053 CHIP CAP. 0.047uF 10V B GRM155B11A473KA01D K22108801 1- B b2
C 2054 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c4
C 2057 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B c4
C 2058 CHIP CAP. 0.047uF 10V B GRM155B11A473KA01D K22108801 1- B a2
C 2061 CHIP CAP. 220pF 50V B GRM155B11H221KA01D K22178801 1- B c4
C 2062 CHIP CAP. 100pF 50V CH GRM1552C1H101JA01D K22178236 1- B c4
C 2063 CHIP CAP. 0.047uF 10V B GRM155B11A473KA01D K22108801 1- B a2
C 2064 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B b4
C 2069 CHIP CAP. 0.047uF 10V B GRM155B11A473KA01D K22108801 1- B a2
C 2070 CHIP CAP. 0.047uF 10V B GRM155B11A473KA01D K22108801 1- B a2
C 2075 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c5
C 2076 CHIP TA.CAP. 47uF 4V TMCP0G476MTRF K78060050 1- B c4
C 2077 CHIP CAP. 100pF 50V CH GRM1552C1H101JA01D K22178236 1- A A4
C 2078 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A A4
C 2081 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c2
C 2084 CHIP TA.CAP. 47uF 4V TMCP0G476MTRF K78060050 1- B b2
C 2085 CHIP CAP. 0.1uF 25V B GRM155B31E104KA87D K22148838 1- B b1
C 2086 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c2
C 2087 CHIP CAP. 0.0047uF 50V B GRM155B11H472KA01D K22178838 1- A A1
C 2088 CHIP CAP. 0.0047uF 50V B GRM155B11H472KA01D K22178838 1- A A1
C 2089 CHIP CAP. 1uF 16V B GRM155B31C105KA12D K22128817 1- A B1
C 2090 CHIP CAP. 1uF 16V B GRM155B31C105KA12D K22128817 1- A B1
C 2091 CHIP CAP. 0.1uF 25V B GRM155B31E104KA87D K22148838 1- B b2
C 2092 CHIP CAP. 1uF 16V B GRM155B31C105KA12D K22128817 1- A B1
C 2093 CHIP CAP. 1uF 16V B GRM155B31C105KA12D K22128817 1- A B1
C 2094 CHIP CAP. 10pF 50V CH GRM1552C1H100JA01D K22178212 1- B a1
C 2095 CHIP CAP. 9pF 50V CH GRM1552C1H9R0DA01D K22178211 1- B a1
C 2095 CHIP CAP. 7pF 50V CH GRM1552C1H7R0DA01D K22178209 11- B a1
C 2097 CHIP CAP. 10pF 50V CH GRM1552C1H100JA01D K22178212 1- B a1
C 2098 CHIP CAP. 5pF 50V CH GRM1552C1H5R0CA01D K22178207 1- B a1
C 2100 CHIP CAP. 8pF 50V CH GRM1552C1H8R0DA01D K22178210 1- B a2
C 2101 CHIP CAP. 8pF 50V CH GRM1552C1H8R0DA01D K22178210 1- B a1
C 2102 CHIP CAP. 7pF 50V CH GRM1552C1H7R0DA01D K22178209 1- B c1
C 2103 CHIP CAP. 220pF 50V B GRM155B11H221KA01D K22178801 1- B b3
C 2104 CHIP CAP. 0.0082uF 16V B GRM155B11C822KA01D K22128801 1- B b3
C 2105 CHIP CAP. 220pF 50V B GRM155B11H221KA01D K22178801 1- B b3
C 2106 CHIP CAP. 0.01uF 16V B GRM155B11C103JA01D K22128814 1- B b3
C 2107 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B b3
C 2109 CHIP CAP. 10uF 4V X5R GRM155R60G106ME44D K22179733 1- B b3
C 2110 CHIP CAP. 10uF 4V X5R GRM155R60G106ME44D K22179733 1- B b3
C 2112 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b4
C 2113 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b3
C 2114 CHIP CAP. 22uF 6.3V B GRM188R60J226MEA0D K22084807 1- B c4
C 2116 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b3
ø
Please contact YAESU when replacing the CNTL-UNIT.
