Yaesu FT-2DR - S 2 xxx; SC2 xxx; TH2 xxx; X 2 xxx

CNTL-13
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG YAESU P/N VERS. LOT SIDE LAY ADR
CNTL Unit
Parts List
FT2DR/DE Technical Supplement
R 2235 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B b3
R 2243 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B b3
R 2244 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B b4
R 2245 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B b4
R 2246 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B b4
R 2247 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B b4
R 2249 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B b4
R 2251 CHIP RES. 330k 1/16W 0.5% MCR01MZPD3303 J24189330 1- B b4
R 2252 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 1- B b3
R 2253 CHIP RES. 180 1/16W 5% RMC1/16S 181JTH J24189016 1- B b4
R 2255 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B b4
R 2257 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- B b4
R 2258 CHIP RES. 6.8k 1/16W 5% RMC1/16S 682JTH J24189035 1- B b4
R 2259 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B b4
R 2263 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B b4
R 2264 CHIP RES. 3.9k 1/16W 5% RMC1/16S 392JTH J24189032 1- B b4
R 2265 CHIP RES. 220k 1/16W 0.5% MCR01MZPD2203 J24189389 1- B b4
R 2266 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B b4
R 2268 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B b5
R 2269 CHIP RES. 33k 1/16W 0.5% MCR01MZPD3302 J24189380 1- B b4
R 2270 CHIP RES. 47k 1/16W 0.5% MCR01MZPD4702 J24189382 1- B b4
R 2271 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b4
R 2272 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B b4
R 2273 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b5
R 2274 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 1- B b4
R 2275 CHIP RES. 1M 1/16W 1% RMC1/16SK105FTH J24189541 1- B b4
R 2276 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 1- B b4
R 2277 CHIP RES. 1.2k 1/16W 5% RMC1/16S 122JTH J24189026 1- A A5
R 2278 CHIP RES. 270k 1/16W 0.5% MCR01MZPD2703 J24189329 1- B b4
R 2279 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B b3
R 2280 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B b3
R 2281 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B b3
R 2282 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B c3
R 2283 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B b4
R 2284 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B b3
R 2285 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B b3
R 2286 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B b3
R 2287 CHIP RES. 68k 1/16W 5% RMC1/16S 683JTH J24189047 1- B c3
R 2288 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B c3
R 2292 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B b4
R 2293 CHIP RES. 15k 1/16W 0.5% RR0510R-153-D J24189147 1- B b3
R 2294 CHIP RES. 47k 1/16W 0.5% RR0510R-473-D J24189159 1- B b3
R 2295 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B b2
R 2296 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B b2
R 2298 CHIP RES. 1 1/16W 5% RMC1/16S 1R0JTH J24189319 1- B a4
R 2299 CHIP RES. 1 1/16W 5% RMC1/16S 1R0JTH J24189319 1- B b4
R 2300 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b4
R 2301 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1 B c2
R 2301 CHIP RES. 33k 1/16W 1% RMC1/16SK333FTH J24189494 2- B c2
R 2302 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B a2
R 2303 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B a2
R 2304 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B a2
R 2305 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B a2
R 2306 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B a3
R 2307 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B b1
R 2308 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B b2
R 2309 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B b2
S 2001 TACT SWITCH SKRMAAE010 N5090140 1- A A4
S 2002 TACT SWITCH SKRMAAE010 N5090140 1- A A4
S 2003 TACT SWITCH SKRMAAE010 N5090140 1- A B4
S 2004 TACT SWITCH SKRMAAE010 N5090140 1- A B4
S 2005 TACT SWITCH SKRMAAE010 N5090140 1- A B4
S 2006 TACT SWITCH SKRMAAE010 N5090140 1- A C4
S 2007 TACT SWITCH SKRMAAE010 N5090140 1- A C4
S 2008 TACT SWITCH EVQP8403M N5090173 1- B c3
S 2009 TACT SWITCH EVQP8403M N5090173 1- B c1
S 2010 TACT SWITCH EVQP8403M N5090173 1- B c3
S 2011 TACT SWITCH EVQP8403M N5090173 1- B c2
SC2001 SHIELD CASE (DSP) RA6024300 1- B b3
TH2001 THERMISTOR NCP15WL473J03RC G9090175 1- B c2
X 2001 XTAL OSC 4.9152MHz NZ2520SB 4.9152MHZ H9501500 1- B c4
X 2002 XTAL OSC 6.144MHz NZ2520SB 6.144MHZ H9501510 1- B c4
X 2003 XTAL NX3225SA 12MHz 12.000MHZ H0103441 1- B a1
