RF Unit

DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE

LAY ADR.

C 1062 CHIP CAP. 4pF 50V CH UMK105CH040CW-F K22178252 1- A B2

C 1063 CHIP CAP. 4pF 50V CH UMK105CH040CW-F K22178252 1- A B2

C 1064 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B2

C 1065 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B2

C 1066 CHIP CAP. 22pF 50V CH UMK105CH220JW-F K22178266 1- B b2

C 1067 CHIP CAP. 8pF 50V CH UMK105CH080DW-F K22178256 1- A B1

C 1068 CHIP CAP. 6pF 50V CH UMK105CH060DW-F K22178254 1- A B2

C 1069 CHIP CAP. 10pF 50V CH UMK105CH100DW-F K22178258 1- A B2

C 1071 CHIP CAP. 8pF 50V CH UMK105CH080DW-F K22178256 1- B b2

C 1072 CHIP CAP. 22pF 50V CH UMK105CH220JW-F K22178266 1- A B2

C 1074 CHIP CAP. 8pF 50V CH UMK105CH080DW-F K22178256 1- B b2

C 1075 CHIP CAP. 8pF 50V CH UMK105CH080DW-F K22178256 1- A B2

C 1076 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B2

C 1077 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B b2

C 1078 CHIP CAP. 22pF 50V CH UMK105CH220JW-F K22178266 1- B c2

C 1079 CHIP CAP. 68pF 50V CH UMK105CH680JW-F K22178278 1- B c2

C 1080 CHIP CAP. 22pF 50V CH UMK105CH220JW-F K22178266 1- B b2

C 1081 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B b2

C 1082 CHIP CAP. 82pF 50V CH UMK105CH820JW-F K22178280 1- B b2

C 1083 CHIP CAP. 120pF 50V CH UMK105CH121JW-F K22178284 1- B b2

C 1084 CHIP CAP. 12pF 50V CH UMK105CH120JW-F K22178260 1- B b2

C 1085 CHIP CAP. 3pF 50V CJ UMK105CJ030CW-F K22178251 1- B b3

C 1086 CHIP CAP. 22pF 50V CH UMK105CH220JW-F K22178266 1- B b3

C 1087 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B b3

C 1088 CHIP CAP. 8pF 50V CH UMK105CH080DW-F K22178256 1- B b3

C 1089 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c2

C 1090 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B d2

C 1091 CHIP CAP. 100pF 50V CH UMK105CH101JW-F K22178282 1- B c2

C 1092 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c3

C 1093 CHIP CAP. 68pF 50V CH UMK105CH680JW-F K22178278 1- B c2

C 1094 CHIP CAP. 3pF 50V CJ UMK105CJ030CW-F K22178251 1- B c2

C 1095 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c3

C 1096 CHIP CAP. 100pF 50V CH UMK105CH101JW-F K22178282 1- B c2

C 1097 CHIP CAP. 5pF 50V CH UMK105CH050CW-F K22178253 1- B c2

C 1098 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c3

C 1099 CHIP CAP. 5pF 50V CH UMK105CH050CW-F K22178253 1- B c3

C 1100 CHIP CAP. 22pF 50V CH UMK105CH220JW-F K22178266 1- B c3

C 1101 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c3

C 1102 CHIP CAP. 1pF 50V CK UMK105CK010CW-F K22178248 1- B c3

C 1103 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B d3

C 1104 CHIP CAP. 27pF 50V CH UMK105CH270JW-F K22178268 1- B c2

C 1105 CHIP CAP. 82pF 50V CH UMK105CH820JW-F K22178280 1- B c2

C 1106 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B c3

C 1107 CHIP CAP. 27pF 50V CH UMK105CH270JW-F K22178268 1- B c3

C 1108 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d3

C 1109 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d3

C 1110 CHIP CAP. 12pF 50V CH UMK105CH120JW-F K22178260 1- A B2

C 1111 CHIP CAP. 0.5pF 50V CK UMK105CK0R5CW-F K22178247 1- A B2

C 1112 CHIP CAP. 7pF 50V CH UMK105CH070DW-F K22178255 1- A B2

C 1113 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A2

C 1114 CHIP CAP. 33pF 50V CH UMK105CH330JW-F K22178270 1- A B2

C 1115 CHIP CAP. 1pF 50V CK UMK105CK010CW-F K22178248 1- A B2

C 1116 CHIP CAP. 2pF 50V CK UMK105CK020CW-F K22178250 1- A B2

C 1117 CHIP CAP. 33pF 50V CH UMK105CH330JW-F K22178270 1- A B2

C 1118 CHIP CAP. 2pF 50V CK UMK105CK020CW-F K22178250 1- A B2

C 1119 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A C2

C 1120 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A C2

C 1121 CHIP CAP. 8pF 50V CH UMK105CH080DW-F K22178256 1- A B2

C 1122 CHIP CAP. 9pF 50V CH UMK105CH090DW-F K22178257 1- A B2

C 1123 CHIP CAP. 6pF 50V CH UMK105CH060DW-F K22178254 1- A B2

Antenna Impedance	50 Ohms
Frequency Coverage RX	0.5-999 MHz (cellular blocked)
Number of Memory Channels	900
Operating Temperature Range	-20°C to +60°C
Modes	FM, AM, WFM
Channel Steps	5/10/12.5/15/20/25/50/100 kHz
Supply Voltage	7.2V DC
Current Consumption	1.5 A (TX)
Waterproof	Yes
