RF Unit

PCB with Components (with VCO Unit) USA CB7372002

PCB with Components (with VCO Unit) EXPORT CB7372003

PCB with Components (with VCO Unit) GERMANY CB7372004

Printed Circuit Board FR008200C 1-

C 1001 CHIP CAP. 2pF 50V CK UMK105CK020CW-F K22178250 1- A A1

C 1002 CHIP CAP. 2pF 50V CK UMK105CK020CW-F K22178250 1- A A1

C 1003 CHIP CAP. 22pF 50V CH UMK105CH220JW-F K22178266 1- A B2

C 1004 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B2

C 1005 CHIP CAP. 100pF 50V CH UMK105CH101JW-F K22178282 1- A B1

C 1006 CHIP CAP. 56pF 50V CH UMK105CH560JW-F K22178276 1- B c2

C 1007 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c2

C 1008 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c1

C 1009 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B c2

C 1010 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d2

C 1011 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B d2

C 1013 CHIP CAP. 3pF 50V CJ UMK105CJ030CW-F K22178251 1- A A1

C 1014 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A1

C 1015 CHIP CAP. 6pF 50V CH UMK105CH060DW-F K22178254 1- A A2

C 1016 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A2

C 1017 CHIP CAP. 3pF 50V CJ UMK105CJ030CW-F K22178251 1- A A2

C 1018 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A2

C 1019 CHIP CAP. 33pF 50V CH UMK105CH330JW-F K22178270 1- A B1

C 1021 CHIP CAP. 100pF 50V CH UMK105CH101JW-F K22178282 1- A B1

C 1023 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B1

C 1024 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B1

C 1025 CHIP CAP. 4pF 50V CH UMK105CH040CW-F K22178252 1- A B1

C 1026 CHIP CAP. 22pF 50V CH UMK105CH220JW-F K22178266 1- A B1

C 1027 CHIP CAP. 33pF 50V CH UMK105CH330JW-F K22178270 1- B c2

C 1028 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c2

C 1029 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A B2

C 1030 CHIP CAP. 68pF 50V CH UMK105CH680JW-F K22178278 1- B c2

C 1031 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c2

C 1032 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B b1

C 1033 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c2

C 1034 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B c2

C 1035 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B c2

C 1036 CHIP CAP. 56pF 50V CH UMK105CH560JW-F K22178276 1- B c2

C 1037 CHIP CAP. 220pF 25V CH GRM36CH221J25PT K22148203 1- B c2

C 1038 CHIP CAP. 68pF 50V CH UMK105CH680JW-F K22178278 1- B c2

C 1040 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c2

C 1041 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d2

C 1042 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c2

C 1043 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B d2

C 1044 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d3

C 1045 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- B d2

C 1046 CHIP CAP. 22pF 50V CH UMK105CH220JW-F K22178266 1- B d2

C 1047 CHIP CAP. 22pF 50V CH UMK105CH220JW-F K22178266 1- B d3

C 1048 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B d2

C 1049 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B d2

C 1051 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d3

C 1052 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A C3

C 1053 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A C3

C 1054 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A C3

C 1055 CHIP CAP. 22pF 50V CH UMK105CH220JW-F K22178266 1- A A2

C 1056 CHIP CAP. 1pF 50V CK UMK105CK010CW-F K22178248 1- A B2

C 1057 CHIP CAP. 0.001uF 50V B UMK105B102KW-F K22178829 1- A A2

C 1058 CHIP CAP. 22pF 50V CH UMK105CH220JW-F K22178266 1- A A2

C 1059 CHIP CAP. 1pF 50V CK UMK105CK010CW-F K22178248 1- A B2

C 1060 CHIP CAP. 2pF 50V CK UMK105CK020CW-F K22178250 1- A B2

C 1061 CHIP CAP. 33pF 50V CH UMK105CH330JW-F K22178270 1- A B2

Parts List

DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE

LAY ADR.

Antenna Impedance	50 Ohms
Frequency Coverage RX	0.5-999 MHz (cellular blocked)
Number of Memory Channels	900
Operating Temperature Range	-20°C to +60°C
Modes	FM, AM, WFM
Channel Steps	5/10/12.5/15/20/25/50/100 kHz
Supply Voltage	7.2V DC
Current Consumption	1.5 A (TX)
Waterproof	Yes
