Yaesu VX-7R - TECHNICAL - Page 56

56
VCO Unit
D 4012 DIODE 1SS400 TE61 G2070634 1- A
D 4013 DIODE 1SV325(TPH3) G2070848 1- A
D 4014 DIODE HSC277TRF G2070584 1- A
D 4015 DIODE 1SV325(TPH3) G2070848 1- A
J 4001 CONNECTOR AXK5F10335P P1091136 1- B
J 4002 CONNECTOR AXK5F10335P P1091136 1- B
L 4001 M.RFC 1uH LK1608 1R0K-T L1690687 1- A
L 4002 M.RFC 0.0082uH 5% C1608CA-8N2J L1691095 1- A
L 4003 M.RFC 0.0082uH 5% C1608CA-8N2J L1691095 1- A
L 4004 M.RFC 1uH LK1608 1R0K-T L1690687 1- A
L 4005 M.RFC 4.7uH LK1608 4R7K-T L1690688 1- A
L 4006 M.RFC 0.018uH 2% C1608CA-18NG L1691035 1- A
L 4007 M.RFC 0.018uH 2% C1608CA-18NG L1691035 1- A
L 4008 M.RFC 1uH LK1608 1R0K-T L1690687 1- A
L 4009 M.RFC 4.7uH LK1608 4R7K-T L1690688 1- A
L 4010 M.RFC 0.1uH 2% C1608CA-R10G L1691045 1- A
L 4011 M.RFC 1uH LK1608 1R0K-T L1690687 1- A
L 4012 M.RFC 0.33uH LK1608 R33K-T L1690412 1- A
L 4013 M.RFC 0.033uH HK1608 33NJ-T L1690522 1- A
L 4014 M.RFC 0.1uH LK1608 R10K-T L1690407 1- A
L 4015 M.RFC 0.22uH 2% C1608CA-R22G L1691103 1- A
Q 4001 TRANSISTOR DTC143ZE TL G3070102 1- A
Q 4002 TRANSISTOR EC3H07B-TL G3070286 1- A
Q 4003 TRANSISTOR DTC143ZE TL G3070102 1- A
Q 4004 TRANSISTOR EC3H07B-TL G3070286 1- A
Q 4005 TRANSISTOR EC3H07B-TL G3070286 1- A
Q 4006 TRANSISTOR EC3H07B-TL G3070286 1- A
Q 4007 TRANSISTOR DTC143ZE TL G3070102 1- A
R 4001 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A
R 4002 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A
R 4003 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- A
R 4004 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A
R 4005 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 1- A
R 4006 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A
R 4007 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 1- A
R 4008 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A
R 4009 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A
R 4010 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- A
R 4011 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A
R 4012 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A
R 4013 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A
R 4014 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A
R 4015 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A
R 4016 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A
R 4017 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- A
R 4018 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A
R 4019 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A
R 4020 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A
R 4021 CHIP RES. 390 1/16W 5% RMC1/16S 391JTH J24189020 1- A
R 4022 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 1- A
R 4023 CHIP RES. 3.9k 1/16W 5% RMC1/16S 392JTH J24189032 1- A
R 4024 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A
R 4025 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A
R 4026 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A
R 4027 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A
SHIELD CASE VCO RA0400300 1-
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR.
