Yakima DoubleDown 2 - Installation Steps Part 1; Install Tongue; Prepare Hitch Bolt; Adapter Adjustment for Hitch Size

1033437B-2/15
IF YOUR VEHICLE'S HITCH IS 1 1/4":
REMOVE THE 2" HITCH ADAPTER,
AND THE PLASTIC SLEEVE.
Remove the bolt from
the adapter using
the hex wrench.
Remove the
adapter, and
sleeve from the
tongue.
FOR 2" HITCHES: PROCEED
TO NEXT STEP.
Use this
hole.
INSTALL TONGUE.
Push the tongue into the hitch
plate, aligning the holes.
• Install hex bolt and a flat washer.
• Add a second washer, attach a nut.
INSERT TONGUE INTO
VEHICLE'S HITCH.
IF SPARE TIRE CAUSES
INTERFERENCE, DO NOT
USE THIS PRODUCT!
Align the holes in the receiver
to the holes in the tongue.
• TIGHTEN with adjustable wrench.
INSTALL LARGE BOLT, LOCK-WASHER, AND WASHER.
• Install safety pin.
• Install bolt, lock-washer, and washer
from right side of receiver.
