6100009518_8002495_8002496_ 9802406_ 9802407-Rev2.0 3/16
COMPATIBLE TOW BALLS
INCOMPATIBLE TOW BALLS
Ensure you have
removed the tow
ball cover
Ensure you
have removed
any Shin
Guards
OR
+
50 MM ≥
Height from base to center of ball to be 50 mm+
+
75 MM >
AND
75 MM ≤
Tongue width less than 75 mm
65 MM ≥
Height from base to center of ball to be 65 mm+
Distance from center of ball to end of lat
base to be 70 mm+
70 MM ≥
TROUBLESHOOTING
Duo and Multi Ball
tow balls
Quick change style tow balls
Tow balls with welded supports
or tabs often interfere with the
plastic covers on the carrier.
Tongue width greater than 75 mm
To Next Page
