Yakima LoadWarrior - Finalizing Installation and Usage; Load Bar and End Clamp Attachment; Accessory Mounting Guidelines; Safety and Hatch Clearance

1031908E-3/8
ATTACH THE KNOBS:
Engage the threads of
the bolts.
CHECK INSTALLATION:
Make sure installation is secure
by tugging at basket.
On some
vehicles, hatch
interference is
unavoidable.
TO REMOVE THE BASKET, DO NOT
DISASSEMBLE THE HARDWARE.





USE CAUTION WHEN

T-BOLT IS LOCKED

bolt is turned inside
the hole:


SECURE THE
BASKET TO


POSITION THE SUPPORT BRACKETS
ABOVE 

OUTSIDE of the basket


face 
It may be necessary to
move the bracket to a new
position, or to adjust the
basket position.



Position cover bracket onto installed

Hooked tab should cover the larger
support bar.
Arrow points inboard
to center of vehicle.

Insert bolt into round hole,
and T-bolt into slotted hole.
The basket should NOT
SLIDE on the bars.
Tighten knobs if
necessary.

