Yakima Q Tower - Anatomy of the Q-Tower; Q-Clip Families Explained

1033430H-2/33
GOLD SLIDER
HASH
MARKS
CAM
COVER
ADJUSTMENT POST STICKER
Q-Clip
BASE PAD
VINYL PADS
LOCK
HOUSING
CLIP FASTENER
LOCK CORE
(OPTIONAL)
END
CAP
BLADED AIRCRAFT RAIN
GUTTER
HOOK
Q-Clip families.
Overview
Prepare for
installation
Install towers
in front
Install towers
in rear
Perform safety
checks
YOU ARE
HERE
Anatomy of the Q-Tower.
There are several shapes and sizes of Q-Clips, but they all fall into five Q-Clip categories. Every vehicle
needs a specific Q Clip to install Q-Towers. For this reason Q-Clips must be purchased separately. Examples
of the five different categories of Q Clips are depicted below.
OEM
(ATTACHES TO FACTORY
INSTALLED VEHICLE FEATURE)
CLIP
HOLDER
