Yale 3000 - 3000 Parallel Arm Installation (Right Hand Shown)

5
For technical support contact Yale
®
at 800.438.1951
An ASSA ABLOY Group brand
Copyright © 2019, ASSA ABLOY Access and Egress Hardware Group, Inc.
All rights reserved. Reproduction in whole or in part without the express written permission
of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
80-9303-3207-010 Rev 1 05/19
2. Close latch and sweep
valves.
4. Install soft plate and mount closer.
5. Install Hold Open arm to plate. 6. Place main arm on closer spindle and rotate.
R
o
t
a
t
e
Dial DOWN
Left and Right Hand
3. Remove dial from
Hold Open arm.
IMPORTANT
Door/Wall/Hardware/Jamb
*
conditions permitting
Door
Opening
To 120°
121° to 180°
*
A
9-1/2
(241)
7
(178)
B
3-3/4
(95)
1-1/4
(32)
C
L
2-3/4
(70)
A
3/8
(10)
1/2
(13)
7/16
(11)
2
(50)
3-5/8
(92)
3/4
(19)
B
Top of
Door
Frame
12
(304.8)
3000 Parallel Arm Installation (Right Hand Shown)
1. Prepare door and frame.
