Specifications
All devices
EMC
Tested to EN 300 220-1 and ETS
300 683
Environmental conditions
-10°C to 40°C, relative humidity
70% non-condensing for all units
except the external siren. Siren: -20°C
to 50°C, relative humidity 95% non-
condensing
Radio operational range
30m in a typical domestic
installation
Can vary depending on building
construction and RF environment.
Housings ABS
Control unit
Keys
▼ Scrolls display downwards
▲ Scrolls display upwards
c Program button, telephone
dialler
b Phone number pause
a When in programming
mode, clears the screen or
return to previous menu;
back space for telephone
numbers
Device codes
DC Door/window contact
PIR PIR movement detector
SD Smoke detector
RC Keyfob remote control
KP Keypad remote control
WTR Help watch
Control unit illumination Display is back lit
when the unit is mains powered.
Housing ABS
Siren Output 95dBA sound pressure @
1m minimum
Zones 20 radio devices
Radio system 433.92MHz AM Integral
transmitter and super heterodyne
receiver with jamming detection
Power supply Plug top adaptor type, input
230VAC 50Hz, output 9VDC, 500ma,
tested to EN 60 950
Rechargeable battery Nickel cadmium
7.2V, 600mah, charge time 72h,
standby duration 8h
Telephone interface Tested to TBR 21.
Hands free vox operated, 6
programmable numbers with 4
different pre-recorded messages
REN rating 1
Siren
Siren output 104dBA sound pressure @
1m minimum
Radio 433.92MHz AM super heterodyne
receiver with jamming detection
Power supply 6V, 4 x D alkaline cells. 3
years minimum typical service life
PIR movement detector
Alarm processing Microprocessor
controlled dual edge sequential pulse
count with pulse length discrimination
Radio 433.92MHz AM transmitter
Power supply 4.5V, 3 x AA alkaline cells.
3 years minimum typical domestic
service life, 1-minute sleep timer
Movement detection range 15m, 110°
Door/window contact
Radio Microprocessor controlled
433.92MHz AM transmitter
Power supply 3V, 2 x AAA alkaline cells. 3
years minimum typical domestic
service life @ 50 activations a day
Smoke detector
Radio Microprocessor controlled
433.92MHz AM transmitter
Power supply 6V, 4 x AAA alkaline cells. 3
years minimum typical domestic
service life
Keyfob remote control
Radio Microprocessor controlled
433.92MHz AM transmitter
Power supply 12V 23A/MN21 alkaline
miniature "lighter" battery. 3 years
minimum typical domestic service life
Keypad remote control
Radio Microprocessor controlled
433.92MHz AM transmitter
Power supply 9V alkaline PP3. 3 years
minimum typical domestic service life
Help button
EMCTested to EN 300 220-1 and ETS
300 683
Environmental conditions -10°C to
40°C, relative humidity 70% non-
condensing
Radio operational range 30m in a
typical domestic installation. Can vary
depending on building construction and
RF environment
Radio Microprocessor controlled
433.92MHz AM transmitter
Power supply 12V 23A/MN21 alkaline
miniature “lighter battery”. 3 years
typical domestic service life
Model: HSA3800
HSA3020
HSA3060
HSA3010
HSA3050
HSA3045
HSA3080
HSA3030
HSA3070
