Yale HSA3800 User Manual

3
Contents
Contents
1 Location planning 4
2 Unpack the parts 6
3 Easy install programming 8
4 Installation/mounting 11
5 Using the system 13
Configuring your system 15
Testing the system 17
Installing and using accessories 18
Telephone connection and programming 20
Dialling and call acknowledgment 22
Two-way voice communication 23
Hands free calling 23
Changing the batteries 25
Trouble shooting 26
Specifications 27
Key points Back cover
Recommended installation sequence
We recommend you follow the simple install
sequence, headings numbered 1-5.
Subsequent sections provide:
• Use of additional accessory devices including
keypad and keyfob remote controls, smoke
alarm and help watch
•Telephone connection
• Advanced protection and features
Carton contents
Control unit and mounting base
External siren
Dummy siren
2 x PIR
2 x Door contact
2 x Door contact magnet
2-metre 500mA 9V power adaptor
3-metre telephone cable
2-way telephone adaptor
4 x 1.5V AAA alkaline cells
6 x 1.5V AA alkaline cells
4 x 1.5V D alkaline cells
2 x Large adhesive pad
2 x Small adhesive pad
4 x small wall plugs
12 x medium wall plugs
8 x large wall plugs
8 x 4mm x 30mm cross head fixing screws
4 x 3.5mm x 22mm cross head fixing screws
12 x 3.5mm x 16mm cross head fixing screws
4 x 3mm x 12mm cross head fixing screws
2 x window stickers
6 x quick reference cards
HSA3020 Passive infra-red (PIR) detector
HSA3030 3 x Passive infra-red (PIR) detectors
HSA3010 Door/window contact
HSA3090 Multiple door/window contact switches
HSA3060 Remote control (keyfob)
HSA3080 Remote keypad
HSA3045 Help button
HSA3070 Smoke detector
HSA3050 External siren
Accessories available
