Yale inTouch Installation And Programming Instructions

2
CAUTION: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
IMPORTANT: The accuracy of the door preparation is critical for the proper functioning
and security of this cylindrical product. Misalignment can cause premature wear and a
lessening of security.
Finish Care: This lockset is designed to provide the highest standard of product quality
and performance. Care should be taken to ensure a long-lasting finish. When cleaning
is required use a soft, damp cloth. Using lacquer thinner, caustic soaps, abrasive cleaners
or polishes could damage the coating and result in tarnishing the finish.
Warnings
.........................................................................................................................
Introduction .....................................................................................................................
Installation
Components and Tools ............................................................................................
Door Preparation ......................................................................................................
Prepare Lock for Installation .................................................................................
Install Lock ............................................................................................................
Hardware Troubleshooting .......................................................................................
Programming
Programming Features-Menus-Keys-Definitions ...............................................
Operation ...........................................................................................................
Miscellaneous Information ......................................................................................
Programming Troubleshooting ...............................................................................
Sample Pin Code Management Sheet ..............................................................
TABLE OF CONTENTS
WARNINGS
INTRODUCTION
Yale® inTouch Stand-alone Touchscreen Access Lock combines robust cylindrical lock-®
sets with a contemporary electronic aesthetic.
Users benefit from an interactive touchscreen that makes day-to-day access effortless and
offers voice-guided programming for simple updates to user information in the event of
staffing changes or security breaches.
inTouch is engineered for quick & easy installation and fits into the standard ANSI/BHMA
A156.115 cylindrical locks with lever door prep with only one additional 3/4" hole and 7
screws including latchbolt and strike.
2
2
3
4
5-6
7-8
8
9-11
12-14
14
15
16-19
Attention Installer: Any retrofit or other field modification to a fire rated opening can
potentially impact the fire rating of the opening, and Yale Locks & Hardware makes no
representations or warranties concerning what such impact may be in any specific situation.
When retrofitting any portion of an existing fire rated opening, or specifying and installing a
new fire-rated opening, please consult with a code specialist or local code official (Authority
Having Jurisdiction) to ensure compliance with all applicable codes and ratings.
An ASSA ABLOY Group brand
80-9150-0075-010 (08-12)

Yale inTouch Specifications

General

Brand	Yale
Model	inTouch
Category	Locks
Language	English
