Yale inTouch Installation And Programming Instructions

3
Lock Installation
#2 phillips screw driver
Lever removal tool (supplied)
3/32" Allen wrench (supplIed)
Door Prep
•
2-1/8" (54mm) hole saw
1" (26mm) boring bit
5/16" (8mm) drill bit
7/64" (2.5mm) drill bit
Chisel & hammer
Parts Illustrations
Tools
Quick Start Instructions
Installation Instructions
Door Marker
Outside Touchscreen Assembly
4 AA Alkaline Batteries
Latchbolt
Strike
Allen Wrench 3/32" (2.5mm)
Lever Removal Tool
Screw Pack (7 screws)
2 Keys (If cylinder included)
In the box, you should find. . .
COMPONENTS AND TOOLS
Outside
Touchscreen
Assembly
Inside
Support
Assembly
Inside
Escutcheon
Inside
Lever
Handle
Battery Cover
4 AA Alkaline
Batteries
Inside Escutcheon Assembly:
Strike
• Inside Support Assembly
• Inside Escutcheon
• Inside Lever Handle
•
INSTALLATION
Battery Cover
•
•
•
•
•
•
•
3/8" or 1/2" drill
•
3/4" (19mm) drill bit
•
Latchbolt
An ASSA ABLOY Group brand
80-9150-0075-010 (08-12)
