1. Touch screen with back of hand or palm to activate.
2. Enter 4-8 digit master code* followed by key.
Lock Response: “Menu mode, enter number, press key to continue.”
3. Enter digit corresponding to the function to be performed followed by the key.
Follow the voice commands.
*The Master code must be registered prior to any other programming PIN of the lock.
Programming Troubleshooting
Symptom Suggested Action
Lock does not respond – door is open and
accessible.
Touchscreen becomes active when pressed w/whole hand. Use a larger area of the hand or fingers
and verify contact with at least 3 area.
If touchscreen numbers are visible, check to see if they respond when pressed.
Check batteries are installed and oriented correctly (polarity) in the battery case.
Check batteries are in good condition; replace batteries* if discharged.
Check to see if touchscreen harness is fully connected and not pinched.
Lock does not respond – door is locked and
inaccessible.
Batteries may be completely discharged.
Apply 9V battery to terminals below the touchscreen for backup power option.
Unit is on for a while then shows no reaction.
Lights dim.
Batteries do not have enough power. Replace batteries*.
Unit chimes to indicate code acceptance, but the
door will not open.
Check the door gaps for any foreign objects between door and frame.
Check that the wire harness is firmly connected to the PCB.
