Yamaha 40A - Chapter 2 BASIC COMPONENTS

E
1
2
3
4
5
6
EMC00010
Chapter 2
BASIC COMPONENTS
MAIN COMPONENTS..............................2-1
OPERATIONS OF CONTROLS AND
OTHER FUNCTIONS ................................2-3
Fuel tank ................................................2-3
Multifunction tiller handle ...................2-4
Remote control .....................................2-7
Choke knob .........................................2-11
Recoil starter handle ..........................2-11
Steering friction adjusting screw......2-12
Trim angle adjusting rod ...................2-12
Shallow water lever ...........................2-13
Power trim/tilt switch .........................2-13
Warning indicator...............................2-14
Digital tachometer..............................2-15
Trim tab ...............................................2-18
Tilt lock mechanism ...........................2-19
Tilt support lever ................................2-20
Top cowling lock lever.......................2-20
WARNING SYSTEM ..............................2-21
Overheat warning...............................2-21
Oil level warning / oil filter
clogging warning ...............................2-22
63B-9-19-2 (E) 4/18/01 11:37 AM Page 1
