2-11
E
EMC87011
Throttle friction adjusting screw
A friction device in the remote control box
provides resistance to movement of the
remote control lever.
This is adjustable for operator preference.
An adjusting screw is located at the front
of the remote control box.
w
Do not overtighten the friction adjusting
screw.
If there is too much resistance, it may be
difficult to move the lever, which could
result in an accident.
Resistance Screw
Increase Turn clockwise
Decrease Turn counterclockwise
701035
EMC42210
CHOKE KNOB
40 MH
Pulling out this knob (setting it to ON)
supplies a rich mixture required to start
the engine.
209015
EMC44010
RECOIL STARTER HANDLE
(If equipped)
Pull the handle gently until resistance is
felt. Then vigorously pull the handle
straight out to crank the engine to start it.
63B-9-19-2 (E) 4/18/01 11:37 AM Page 12
