3-28
E
EMG63010
PROCEDURE FOR TILTING UP
Manual tilt model
1) Remove the fuel-line connection from
the motor. (If the fuel connector is
provided on the motor.)
402035
403024
2) Place the tilt-lock lever in Release.
3) Hold the rear of the top cowling with
one hand, tilt the engine up, and turn
the tilt-support lever to the locked
position and support the engine.
