A5000/A4000
33
cntrl# parameter data range
5 Program Portamento Time 0 - 127
0-120 Program Portamento Rate/Time 0 - 127
0-120 LFO S/H Speed 0 - 127
0-120 AD Input Pan 0 - 127
0-120 AD Input Level 0 - 127
0-120 AD Input L Pan 0 - 127
0-120 AD Input R Pan 0 - 127
0-120 AD Input L Level 0 - 127
0-120 AD Input R Level 0 - 127
0-120 Program Level 0 - 127
0-120 EF1 Level 0 - 127
0-120 EF1 Pan 0 - 127
0-120 EF1 Width 0 - 127
0-120 EF1 Parameter 1 - 16 0 - 127
0-120 EF2 Level 0 - 127
0-120 EF2 Pan 0 - 127
0-120 EF2 Width 0 - 127
0-120 EF2 Parameter 1 - 16 0 - 127
0-120 EF3 Level 0 - 127
0-120 EF3 Pan 0 - 127
0-120 EF3 Width 0 - 127
0-120 EF3 Parameter 1 - 16 0 - 127
0-120 EF4 Level 0 - 127
0-120 EF4 Pan 0 - 127
0-120 EF4 Width 0 - 127
0-120 EF4 Parameter 1 - 16 0 - 127
0-120 EF5 Level 0 - 127
0-120 EF5 Pan 0 - 127
0-120 EF5 Width 0 - 127
0-120 EF5 Parameter 1 - 16 0 - 127
0-120 EF6 Level 0 - 127
0-120 EF6 Pan 0 - 127
0-120 EF6 Width 0 - 127
0-120 EF6 Parameter 1 - 16 0 - 127
0-120 Program LFO Depth 0 - 127
0-120 Control 1 Range 0 - 127
0-120 Control 2 Range 0 - 127
0-120 Control 3 Range 0 - 127
0-120 Control 4 Range 0 - 127
2. Channel messages
Channel messages are received as follows.
When Program Mode = Single and Omni SW is on, The Note ON/OFF, Control Change,
Pitch Bend, After Touch, and Program Change channels have no meaning.
When Program Change SW is enabled and Program Mode = Single the Basic Receive
Channel is used; when Program Mode = Multi the Part 1 receive channel is used. No
program change occurs when off. However, when a program change is received during
internal MIDI sequencer recording, the program change is not recorded even if the Pro-
gram Change SW is off.
Transmission is performed when the internal MIDI sequencer is playing, and when the
KNOB Control function and FKey Play function are being used.
When the MIDI sequencer is playing, the MIDI events that are played back are transmitted
to the internal tone generator, and also simultaneously transmitted via MIDI OUT.When
Knob control used, a value related to the number of rotations is transmitted for the selected
Ch and Control#.
When the FKey Play function is used, Note On/Off messages will be transmitted on the
specified channel with the specified note number and velocity. The velocity used when
transmitting a Note Off message is fixed. Note Off messages will have a velocity of 0 if the
form $8n is used, and if the form $9n is used the velocity will be determined case by case.
2.1. Reception
2.1.1. Note off
Note range = C-2-G8
Velocity range = ignored
2.1.2. Note on/off
Note range = C-2-G8
Velocity range = 0-127
2.1.3. Polyphonic aftertouch
Not received.
2.1.4. Control changes
The following parameters can be controlled.
Parameters which function for each program.
Parameters which function for each MIDI channel of a program
Parameters marked by "*" depend on the Sample Control settings
2.1.5. Mode messages
Messages which function always
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
* (A5000 only)
* (A5000 only)
* (A5000 only)
* (A5000 only)
* (A5000 only)
* (A5000 only)
* (A5000 only)
* (A5000 only)
* (A5000 only)
* (A5000 only)
* (A5000 only)
* (A5000 only)
*
*
*
*
*
Parameters marked by "*" depend on the Program Control settings.
cntrl# parameter data range
7 Volume (Level) 0 - 127
10 Pan 0 - 127
64 Sustain 0 - 127
65 Portament ON/OFF 0 - 127
66 Sostenute 0 - 127
Parameters which function for samples or sample banks
cntrl# parameter data range
0-120 Pitch Mod Depth 0 - 127
0-120 Amp Mod Depth 0 - 127
0-120 Cutoff Mod Depth 0 - 127
0-120 Cutoff Bias 0 - 127
0-120 Filter Q/Width 0 - 127
0-120 Pan Bias 0 - 127
0-120 Pitch Bias 0 - 127
0-120 Sample Level 0 - 127
0-120 LFO Speed 0 - 127
0-120 LFO Delay 0 - 127
0-120 AEG Attack 0 - 127
0-120 AEG Decay 0 - 127
0-120 AEG Sustain Level 0 - 127
0-120 AEG Release 0 - 127
0-120 PEG Attack 0 - 127
0-120 PEG Decay 0 - 127
0-120 PEG Release 0 - 127
0-120 PEG Init Level 0 - 127
0-120 PEG Sustain Level 0 - 127
0-120 FEG Attack 0 - 127
0-120 FEG Decay 0 - 127
0-120 FEG Release 0 - 127
0-120 FEG Init Level 0 - 127
0-120 FEG Sustain Level 0 - 127
0-120 FEG Level 0 - 127
0-120 Pitch Bend 0 - 127
0-120 Wave Start Address 0 - 127
0-120 Cutoff Distance 0 - 127
0-120 Filter Gain 0 - 127
0-120 Sample Portamento Rate/Time 0 - 127
0-120 Sample Control 1 Range 0 - 127
0-120 Sample Control 2 Range 0 - 127
0-120 Sample Control 3 Range 0 - 127
0-120 Sample Control 4 Range 0 - 127
0-120 Sample Control 5 Range 0 - 127
0-120 Sample Control 6 Range 0 - 127
cntrl# parameter data range
120 All sound off 0 - 127
121 Reset all controllers 0 - 127
123 All notes off 0 - 127
Messages which function for samples or sample banks
cntrl# parameter data range
126 mono mode 0 - 127
127 poly mode 0 - 127
2.1.6. Program changes
When a program change message is received, the corresponding program is selected for
playbackand editing. Nothing occurs if the Program Change SW is disabled (even when
internal sequencer recording is off). If Program Mode = Single, program change is re-
ceived via the Basic Receive Channel (any receive channel when Omni is on). When
Program Mode = Multi the Part 1 receive channel is used.
2.1.7. Pitch bend
The 7 bits of the MSB are used.
For functions marked"* indicates Program (or Sample) control" in "Control Change" of
3.1.4, pitch bend can be used for ctrl#.
2.1.8. Channel aftertouch
Received.
For functions marked "* indicates Program (or Sample) control" in "Control Change" of
2.1.4, channel aftertouch can be used for ctrl#
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
