Yamaha A5000 - Panel Layout; Front Panel; Rear Panel

A5000/A4000
4
PANEL LAYOUT
Front Panel
Rear Panel
1 AC inlet
2 Midi In-A, In-B, Out, Thru-A, Thru-B (A5000)
connectors / Midi In, Out, Thru (A4000) connectors
3 Assignable Out L, R jacks
4 Stereo Out L/Mono, R jacks
5 SCSI connector
6 Optical In, Out connectors
7 Digital In, Out connectors
8 Assignable Out jacks 1-6
1 Master Vol [Master Volume]
2 Rec Vol [Recording Volume]
3 Phones jack
4 Input L, Input R jacks
5 LCD Contrast
6 Display
7 Knobs 1-5
8 Mode buttons
9 Function buttons [F1]-[F6]
10 Command Exit button
11 Assignable button
12 Audition button
13 Floppy Disk Drive
14 Power switch
