3. Tighten the locknut to the specified torque.
CAUTION:
ECB00080
Always tighten the locknut against the adjust-
ing nut, and then tighten it to the specified
torque.
WARNING
EWB00450
This shock absorber assembly contains highly
pressurized nitrogen gas. If the shock absorb-
er assembly is damaged, it could explode
causing injury or property damage. Shock ab-
sorber cylinder damage could also result in
poor handling which could cause an accident.
●
Do not tamper with or attempt to open the
cylinder assembly.
●
Do not subject the shock absorber assembly
to an open flame or other high heat.
●
Do not deform or damage the cylinder in any
way.
●
Do not dispose of a damaged or worn out
shock absorber assembly yourself. Take the
shock absorber assembly to a Yamaha deal-
er for any service.
Tightening torque:
Locknut:
55 Nm (5.5 m·kgf, 40 ft·lbf)
To Next Page
