Yamaha BWS YW100E - Front Brake Lever; Fuel and Oil Tanks

INSTRUMENT AND CONTROL FUNCTIONS
3-4
EAU00158
Front brake lever
The front brake lever is located on
the right handlebar. Pull it toward the
handlebar to apply the front brake.
EAU00163
Rear brake lever
The rear brake lever is located on the
left handlebar. Pull it toward the
handlebar to apply the rear brake.
1. Fuel tank cap 2. Oil tank cap
2
1
EAU02966
Fuel and oil tanks
The fuel tank and oil tank are located
under the seat.
EW000025
w
Be sure the caps are properly in-
stalled before riding the scooter.
4VP-F8199-E1.pm65 2/4/2004, 4:21 PM16
