Yamaha BWS YW100E - Shock Absorber; Wheel Travel; Electrical Specifications

Wheels
Type
Front Cast wheel
Rear Cast wheel
Size
Front MT 3.5 × 10
Rear MT 3.5 × 10
Brakes
Front
Type Single disc brake
Operation Right hand operation
Fluid DOT 3 or DOT 4
Rear
Type Drum brake
Operation Left hand operation
Suspension
Front Telescopic fork
Inner tube outer
diameter 30 mm
Rear Unit swing
Shock absorber
Front Coil spring / oil damper
Rear Coil spring / oil damper
Wheel travel
Front 70 mm
Rear 55 mm
Electrical
Ignition system C.D.I.
Charging system
Type A.C. magneto
Standard output 13~14 V / 4,000rpm
Battery
Type YTX 5 L-BS
Voltage, capacity 12 V, 4 AH
Headlight type S1 bulb
Bulb voltage, wattage × quantity
Headlight 12 V, 25 / 25 W × 2
Tail / brake light 12 V, 5 / 21 W × 1
Turn signal light 12 V, 10 W × 4
SPECIFICATIONS
8-3
4VP-F8199-E1.pm65 2/4/2004, 4:21 PM58
