Yamaha CD-1330 Service Manual

23
CD-1330
CD-1330
No. Port Name Function Name I/O Detail of Function
1 P9_6/ANEX1 (No connected)
2 CLAMP_SW2 P9_5/ANEX0 I Clamp SW2
3 CLAMP_SW1 P9_4 I Clamp SW1
4 TRAY_SW4 P9_3
5 TRAY_SW3 P9_2/TB2IN I Tray SW3 / Loader mechanism specification confirm
6 TRAY_SW2 P9_1/TB1IN I Tray SW2
7 TRAY_SW1 P9_0/TB0IN I Tray SW1
8 BYTE BYTE I GND
9 CNVSS CNVSS Usually GND but VCC1 when writing FLASH
10 XCIN P8_7/XCIN (No connected)
11 XCOUT P8_6/XCOUT (No connected)
12 /RESET /RESET
13 XOUT XOUT
14 VSS VSS GND
15 XIN XIN
16 VCC1 VCC1
17 P8_5/NMI Pull-up resistor required
18 KEY_O/C P8_4/INT2 GND when writing FLASH
19 KEY_PLAY P8_3/INT1 (No connected)
20 IR P8_2/INT0 I Remote control
21 P8_1 (No connected)
22 SEL S700/1330 P8_0
23 CLAMP_MOTOR2 P7_7 O Clamp motor 2
24 CLAMP_MOTOR1 P7_6 O Clamp motor 1
25 TRAY_MOTOR2 P7_5/TA2IN O Tray motor 2
26 TRAY_MOTOR1 P7_4/TA2OUT O Tray motor 1
27 P7_3/CTS2/RTS2/TA1IN (No connected)
28 FL_CLK P7_2/CLK2/TA1OUT O FL control
29 P7_1/RXD2/SCL2/TA0IN (No connected)
30 FL_DATA P7_0/TXD2/SDA2/TA0OUT O FL control
31 DAC_SO/TXO P6_7/TXD1/SDA1 O TxD for DAC control / Rewriting FLASH commonly used
32 RXDO P6_6/RXD1/SCL1 I RxD for rewriting FLASH commonly used
33 DAC_SCLK/CT P6_5/CLK1 O CTS for DAC control / Rewriting FLASH commonly used
34 RTS P6_4/CTS1/RTS1/CTS0/CLKS1 I RTS for rewriting FLASH commonly used
35 COMCMD P6_3/TXD0/SDA0 O MODULE control
36 COMSTS P6_2/RXD0/SCL0 I MODULE control
37 COMCLK P6_1/CLK0 I MODULE control
38 P6_0/CTS0/RTS0 (No connected)
39 P5_7/RDY/CLKOUT (No connected)
40 DRV_STBY P5_6/ALE O MODULE control
41 P5_5/HOLD GND when writing FLASH
42 CD_NRST P5_4/HLDA O MODULE control
43 USB_IN P5_3/BCLK O MODULE control
44 COMCS P5_2/RD O MODULE control
45 CD_INT P5_1/WRH/BHE I MODULE control
46 P5_0/WRL/WR VCC1 when writing FLASH
47 VER_SEL1 P4_7/CS3 (No connected)
48 VER_SEL2 P4_6/CS2 (No connected)
49 P4_5/CS1 (No connected)
50 PCON1 P4_4/CS0 O output RELAY
51 AMUTE P4_3/A19 O Analog mute
52 P4_2/A18 O DAC control
53 DAC_CS1 P4_1/A17 O DAC control
54 DAC_RESET P4_0/A16 O DAC control
55 PCON2 P3_7/A15 (No connected)
56 PCON3 P3_6/A14 (No connected)
57 DOUT_MUTE P3_5/A13 (No connected)
58 LED_POWER P3_4/A12 O Indicator of power supply
59 LED_PDIRECT P3_3/A11 O Indicator of pure direct
60 LED_USB P3_2/A10 O Indicator of SACD
