24
CD-1330
CD-1330
No. Port Name Function Name I/O Detail of Function
61 FL_RES P3_1/A9 O FL control
62 VCC2 VCC2
63 FL_CS P3_0/A8 O FL control
64 VSS VSS
65 USB_FLG P2_7/A7 (No connected)
66 USB_EN P2_6/A6 (No connected)
67 SYS_RICO_C P2_5/A5 (No connected)
68 SYS_RICO_U P2_4/A4 (No connected)
69 R_PLUG P2_3/A3 (No connected)
70 SYS_I/O P2_2/A2 (No connected)
71 SYS_ROCI_C P2_1/A1 (No connected)
72 SYS_ROCI_U P2_0/A0 (No connected)
73 P1_7/D15 (No connected)
74 SYS_DET P1_6/D14/INT4 (No connected)
75 USB_DET P1_5/D13/INT3 (No connected)
76 P1_4/D12 (No connected)
77 P1_3/D11 (No connected)
78 P1_2/D10 (No connected)
79 P1_1/D9 (No connected)
80 P1_0/D8 (No connected)
81 P0_7/AN0_7/D7 O Test point
82 TP336 P0_6/AN0_6/D6 O Test point
83 TP337 P0_5/AN0_5/D5 O Test point
84 TP338 P0_4/AN0_4/D4 I LOAD- monitor
85 TP339 P0_3/AN0_3/D3 O Test point
86 TP340 P0_2/AN0_2/D2 I LOAD+ monitor
87 TP341 P0_1/AN0_1/D1 O Test point
88 TP342 P0_0/AN0_0/D0 O Test point
89 SYS_DM P10_7/AN7/KI3 (No connected)
90 SYS_AD P10_6/AN6/KI2 (No connected)
91 P10_5/AN5/KI1 (No connected)
92 P10_4/AN4/KI0 (No connected)
93 KEY0 P10_3/AN3 I Analog input
94 KEY1 P10_2/AN2 I Analog input
95 KEY2 P10_1/AN1 I Analog input
96 AVSS AVSS
97 VDET P10_0/AN0 I MODULE control
98 VREF VREFF
99 VCC1 AVCC
100 P9_7/ADTRG (No connected)
To Next Page
