Yamaha CD-S3000 Service Manual

AUDIO (Side B)
ABCDEFGH I J
1
2
3
4
5
6
7
CD-S3000
53
Ref no. Location
D5 F4
D6 F6
D7 F3
D8 F6
D13 C4
D14 C5
D15 C5
D16 C5
D17 D3
D18 D3
• Semiconductor Location
Ref no. Location
D19 D4
D20 D4
D21 D5
D22 D5
D23 D6
D24 D6
D303 I3
D304 I6
D305 I3
D306 I6
Ref no. Location
D307 G3
D308 G4
D309 G5
D310 G6
D311 G4
D313 G5
Q15 C4
Q16 C5
Q17 D3
Q18 D4
Ref no. Location
Q19 D5
Q20 D6
Q21 C4
Q22 C5
Q23 D3
Q24 D4
Q25 D5
Q26 D6
Q33 F6
Q34 B4
Ref no. Location
Q47 B5
Q48 C4
Q49 C4
Q50 C5
Q51 C5
Q52 D3
Q53 D3
Q54 D4
Q55 D4
Q56 D5
Ref no. Location
Q57 D5
Q58 D6
Q59 D6
Q60 F6
Q61 C3
Q62 C6
Q301 G3
Q302 G4
Q303 G5
Q304 G6
Ref no. Location
Q309 F4
Q310 F5
Q311 B4
Q312 B4
Q313 C3
Q314 B3
Q315 B3
Q316 C3
Q317 B5
Q318 B5
Ref no. Location
Q319 C6
Q320 B6
Q321 C6
Q322 B6
Q323 F3
Q324 F3

Yamaha CD-S3000 Specifications

General

Frequency range	2 - 20000 Hz
Audio formats supported	MP3, WMA
Signal-to-Noise Ratio (SNR)	116 dB
Total Harmonic Distortion (THD)	0.002 %
CD-R playback	Yes
Playback disc formats	CD audio, SACD
CD changer	No
Device type	HiFi CD player
Product color	Silver
Disc loading type	Tray
Number of optical discs	1 discs
USB 2.0 ports quantity	1

Weight and Dimensions

Depth	440 mm
Width	435 mm
Height	142 mm
Weight	19200 g
