CDX-E400
28
CDX-E400
% : Note on the Main PCB
Of the main PCB part Nos., only the gold (GD) type part Nos. are included in the table. (G, B models)
The only different part between the silver (SI) and gold (GD) type parts is the sheet/FL that is attached to the
fluorescent character display tube. When a SI type main PCB becomes necessary, order a GD type main PCB and a
SI type sheet/FL (V3688400) and replace the sheet/FL of the GD type main PCB with the SI type sheet/FL.
Schm
Ref. PARTNO. Description Market
NewParts
*
Schm
Ref. PARTNO. Description Market
NewParts
*
* V9356200 P.C.B. GD:MAIN R
* V9356300 P.C.B. GD:MAIN GB
CB1 V2731000 CN.FMN 16P
CB6 V4164300 L.EMIT TOTX178A
CB7 VB390100 CN.BS.PIN 5P
CB102 VN394900 CN.BS.PIN 14P
CB301 VF982200 CN.BS.PIN 14P
CB401 VG879900 CN.BS.PIN 2P
C1 UR818100 C.EL 100uF6.3V
C2 VJ599100 C.CE.TUBLR 0.1uF50V
C3 UR818100 C.EL 100uF6.3V
C4 UR818100 C.EL 100uF6.3V
C5 UR837470 C.EL 47uF16V
C6 VF467000 C.CE.TUBLR 1000pF50V
C8 UR838220 C.EL 220uF16V
C10 UR838220 C.EL 220uF16V
C11 VE326000 C.MYLAR.ML 0.1uF50V
C12 UN865220 C.EL 0.22uF50V
C15 UA654150 C.MYLAR 0.015uF50V
C16 UA653330 C.MYLAR 3300pF50V
C19 UA653330 C.MYLAR 3300pF50V
C20 UA654150 C.MYLAR 0.015uF50V
C21 VG287300 C.EL 22uF50V
C22 VG287300 C.EL 22uF50V
C23 UA653220 C.MYLAR 2200pF50V
C24 UA653220 C.MYLAR 2200pF50V
C25 UA652220 C.MYLAR 220pF50V
C26 UA652220 C.MYLAR 220pF50V
C27 VF466800 C.CE.TUBLR 100pF50V
C28 VF467300 C.CE.TUBLR 0.01uF16V
C29 VJ599100 C.CE.TUBLR 0.1uF50V
C30 UR848220 C.EL 220uF25V
C31 VG286200 C.EL 100uF10V
C32 VJ599100 C.CE.TUBLR 0.1uF50V
C33 UR865680 C.EL 0.68uF50V
C34 VG286200 C.EL 100uF10V
C35 UR837100 C.EL 10uF16V
C36 VG287900 C.EL 470uF16V
Z C37 VK534100 C.PP 0.01uF100V
C38 Vi578400 C.EL 6800uF16V
Z C39 VK534100 C.PP 0.01uF100V
C40 UR837470 C.EL 47uF16V
C41 UR828100 C.EL 100uF10V
C42 UR867470 C.EL 47uF50V
C43 UR866470 C.EL 4.7uF50V
C44 UR866470 C.EL 4.7uF50V
C45 UR867470 C.EL 47uF50V
C46 UR866470 C.EL 4.7uF50V
C47 UR868100 C.EL 100uF50V
C48 Vi716700 C.MYLAR 0.01uF50V
C101 VJ599100 C.CE.TUBLR 0.1uF50V
C102 VJ599100 C.CE.TUBLR 0.1uF50V
C103 VJ599100 C.CE.TUBLR 0.1uF50V
C104 V4749000 C.EL 150uF6.3V
C105 VG277700 C.CE.TUBLR 68pF50V
C106 UA653100 C.MYLAR 1000pF50V
C107 UA653150 C.MYLAR 1500pF50V
C108 UA654470 C.MYLAR 0.047uF50V
C109 UN865470 C.EL 0.47uF50V
C110 VE326000 C.MYLAR.ML 0.1uF50V
C111 V4749000 C.EL 150uF6.3V
C112 UR818100 C.EL 100uF6.3V
C113 VJ599100 C.CE.TUBLR 0.1uF50V
C114 VJ599000 C.CE.TUBLR 0.047uF16V
C115 UN865100 C.EL 0.10uF50V
C116 UA654470 C.MYLAR 0.047uF50V
* C117 UA653680 C.MYLAR 6800pF50V
C118 UA654470 C.MYLAR 0.047uF50V
C120 VG276600 C.CE.TUBLR 22pF50V
C122 VJ599100 C.CE.TUBLR 0.1uF50V
C123 VF466900 C.CE.TUBLR 470pF50V
C124 UM397470 C.EL 47uF16V
C125 UA654680 C.MYLAR 0.068uF50V
C126 VJ599100 C.CE.TUBLR 0.1uF50V
C127 VE326000 C.MYLAR.ML 0.1uF50V
C128 VJ599100 C.CE.TUBLR 0.1uF50V
C129 VJ599100 C.CE.TUBLR 0.1uF50V
C130 VA761400 C.CE 47pF50V
C131 VA761400 C.CE 47pF50V
C132 VG290600 C.EL 2.2uF50V
C133 VG290600 C.EL 2.2uF50V
C134 VG290600 C.EL 2.2uF50V
C135 VG290600 C.EL 2.2uF50V
C136 VG286500 C.EL 470uF10V
C137 Vi716700 C.MYLAR 0.01uF50V
C138 UR818100 C.EL 100uF6.3V
C139 VJ599100 C.CE.TUBLR 0.1uF50V
C140 VJ599100 C.CE.TUBLR 0.1uF50V
C141 VJ599100 C.CE.TUBLR 0.1uF50V
C142 VJ599100 C.CE.TUBLR 0.1uF50V
C143 UR818100 C.EL 100uF6.3V
C144 VF467300 C.CE.TUBLR 0.01uF16V
C145 UA652100 C.MYLAR 100pF50V
C146 UA652470 C.MYLAR 470pF50V
C147 UA652470 C.MYLAR 470pF50V
C148 UA652100 C.MYLAR 100pF50V
C149 VG286200 C.EL 100uF10V
C150 VG286200 C.EL 100uF10V
C151 VJ599100 C.CE.TUBLR 0.1uF50V
C152 UR818100 C.EL 100uF6.3V
C160 VJ599100 C.CE.TUBLR 0.1uF50V
C301 VJ599100 C.CE.TUBLR 0.1uF50V
C302 VJ599100 C.CE.TUBLR 0.1uF50V
C303 VG276600 C.CE.TUBLR 22pF50V
* C401 VR814900 C.CE.SAFTY 0.047uF250V
C402 UA654100 C.MYLAR 0.01uF50V
