Yamaha CDX-E400 - Page 28

CDX-E400
CDX-E400
29
Schm
Ref. PARTNO. Description Market
NewParts
*
Schm
Ref. PARTNO. Description Market
NewParts
*
C403 UR828100 C.EL 100uF10V
Z * D1 V8911600 DIODE DIN60‑4084
Z * D2 V8911600 DIODE DIN60‑4084
D3 VD631600 DIODE 1SS133,176
D4 VD631600 DIODE 1SS133,176
D5 VG437400 DIODE.ZENR MTZJ5.1B5.1V
Z D6 VR253700 DIODE.BRG S1NB201A200V
D10 VG437700 DIODE.ZENR MTZJ5.6B5.6V
Z * D11 V8911600 DIODE DIN60‑4084
D12 VG437700 DIODE.ZENR MTZJ5.6B5.6V
D13 VG443300 DIODE.ZENR MTZJ30B30V
Z * D14 V8911600 DIODE DIN60‑4084
D101 VD631600 DIODE 1SS133,176
D102 VD631600 DIODE 1SS133,176
D103 VD631600 DIODE 1SS133,176
D104 VD631600 DIODE 1SS133,176
D105 VD631600 DIODE 1SS133,176
D106 VG436700 DIODE.ZENR MTZJ4.3A4.3V
IC3 XA987A00 IC NJM2068D‑D
IC4 XD201A00 IC M5290P
IC101 XZ652A00 IC AN8399SA
IC102 XW915A00 IC MN35511AL
* IC103 X3245A00 IC.CPU UPD78076GF‑108‑3BA
IC104 XS070A00 IC S‑24C01ADPEEPROM
IC105 XA987A00 IC NJM2068D‑D
IC301 XR188A00 IC LC75710NEFLD
IC302 XF494A00 IC LB1641
* IC303 XV102A00 IC M56789FP
JK1 V3576300 JACK 2P
L1 GE300610 FER.BEAD BL02RN1‑R62T4
Z L401 VU984000 FLTR IE‑UU10.5‑009
L402 V6660800 FER.CORE F5T19x10x10
* PJ1 V7720900 JACK.PIN LPR6520‑E510M
PN1 V3750100 PIN L=50
Q1 iB054430 TR 2SB544D,E,F,G
Q2 VK432900 TR 2SD1915FS,T
Q3 VK432900 TR 2SD1915FS,T
Q4 VK432900 TR 2SD1915FS,T
Q5 VK432900 TR 2SD1915FS,T
Q6 VK432900 TR 2SD1915FS,T
Q7 iA093320 TR 2SA933SQ,R
Q8 VS883300 TR 2SB1565E,F
Q9 VR510800 TR 2SD2396J,K
Q10 VP872600 TR 2SA1708S,T
Q102 VK432900 TR 2SD1915FS,T
R1 HV754100 R.CAR.FP 10 1/4W
Z R44 V2370600 R.FUS 0.47 1/6W
R46 HV755100 R.CAR.FP 100 1/4W
R47 HV755100 R.CAR.FP 100 1/4W
R50 V2370600 R.FUS 0.47 1/6W
R51 HV754100 R.CAR.FP 10 1/4W
R118 VL207800 R.ARRAY RGLE7X473J
R307 HV754100 R.CAR.FP 10 1/4W
ST501 V4040500 SCR.TERM M3 R
ST502 V4040500 SCR.TERM M3 R
SW301 VV020300 SW.TACT SKQNAA
SW302 VV020300 SW.TACT SKQNAA
SW303 VV020300 SW.TACT SKQNAA
SW304 VV020300 SW.TACT SKQNAA
SW305 VV020300 SW.TACT SKQNAA
SW306 VV020300 SW.TACT SKQNAA
Z SW501 VG388100 VOLT.SELCT HXW0244‑01‑080 R
Z T401 XN394A00 TRANS.PWR R
Z T401 XN393A00 TRANS.PWR BG
V301 V3618100 FL.DSPLY 14‑BT‑56GN
XL101 VJ719800 RSNR.CRYS 16.9344MHz
XL102 VU763600 RSNR.CE 5MHz
VQ948800 SHEET.FL GD
% V3688400 SHEET.FL SI
V3747500 SUPRT
V3747400 SPACER.FL T4x6x18
