Yamaha CL3 Installation Guide

CL Editor Installation Guide 5
The following diagram shows how to connect the computer to the CL through a dedicated network.
NOTE You cannot simultaneously control one CL unit from two computers running CL Editor. However, you can control the CL unit using CL
Editor on a computer along with the CL StageMix application installed on an iPad (or iPad2) that is connected via WiFi.
Connecting the computer to the CL
LAN cable
CL consoleComputer
LAN cable
Network switch
or
LAN cable
CL Editor
Network connector

Yamaha CL3 Specifications

General

DJ mixer	-
Product color	Black
Video capability	No
Frequency range	20 - 20000 Hz
Channels quantity	72 channels
Signal delay (@48kHz)	2.5 ms
Supported sample rates	44.1, 48 kHz
Digital sound processing	- bit
Power consumption (typical)	170 W
USB 2.0 ports quantity	1

Weight and Dimensions

Depth	667 mm
Width	839 mm
Height	299 mm
Weight	29000 g
