CDC-E500
CDC-E500
20
■ STANDARD OPERATION CHART
A
Clamp up
refer to MECH TIMING CHART
Carriage change
Clamp down
Drawer open
DISC 1 open by DISC 1 key
“OPEN” appears on the display.
“CLOSE” “CHECK1” appears on the display.
Drawer close
refer to MECH TIMING CHART
Clamp up
Carriage change
Clamp down
Tracking offset auto ADJ
Focus offset auto ADJ
Laser ON
Disc scan
Focus gain rough ADJ
Focus search
Focus lock servo ON
Spindle motor accelerated
Tracking servo ON
Disc servo ON
VCO lock
Tracking gain rough ADJ
DISC 1 play by PLAY key
/TLOCK = “H” → “L” (IC202, 12 pin)
/FLOCK = “H” → “L” (IC202, 11 pin)
